ESS Solar Inverter With Battery Price 300va 500va 1Kva 2Kva 3Kva 4Kva 5Kva 6Kva 7Kva

Input Voltage: 12/24/48VDC | Output Voltage: 110/120/220/230/240VAC±2% | Solar Charging: MPPT/PWM | Max PV Open Circuit Voltage: 50/100/150VDC

1 : Pure sine wave off grid solar inverter with battery and charge controller

2 : Various output interfaces include USB, DC 12V, universal AC socket and AC wiring block

3 : Solar inverter compatible with lithium battery

4 : Solar and AC working modes automatic switching, transfer time ≤ 4ms

5 : Output power factor 100%

Produt Details Download



ESS Series Solar Inverter With Battery



Many customers let us to launch the solar inverter with battery and now finally came out !! The power range of this ESS solar inverter is from 300VA to 7KVA. Note that the power factor here is 100%, that is, 1KVA equals 1KW. Solar inverter built-in 50A, 100A or 200A batteries. The battery type can be lithium battery or lead-acid battery. Our solar inverter also has a built-in charge controller. Users only need to configure a few more solar panels to use portable solar power generation simply. This solar inverter is suitable for home, winnebago, truck, office and even camping. Xindun solar inverter with battery price is beautiful, welcome to inquire.



1Kva 2Kva 5Kva Solar Inverter with Battery Pricesolar inverter with battery and solar controller1kva 2kva 5kva solar inverter with battery price1kva 2kva 5kva solar inverter with battery price1kva 2kva 5kva solar inverter with battery price

2kva solar inverter with battery price




Wiring Diagram Of Solar Inverter With Battery



The wiring of this solar inverter with battery is very simple. Connect the positive and negative poles of the solar panels, put the electrical plug into the universal socket of the inverter, and start the machine to use. Please look over the solar inverter wiring diagram below. In addition, there is an inverter user manual with the product package. You can also contact Xindun's technical consultant to obtain the solar inverter use video.



1kva solar inverter with battery wiring diagram2kva solar inverter with battery wiring diagram5kva solar inverter with battery wiring diagram

2kva solar inverter with battery price




Technical Parameter Of Solar Inverter With Battery



Accept OEM/ODM



Solar Inverter With Battery Specification
Model : ESS 301P 501P 102P 152P/W 202P/W 302P/W 152P8/W8 202P8/W8 302P8/W8 402P/W 502P/W 602P/W 702P/W
Capacity Rated power 300W 500W 1000W 1500W 2000W 3000W 1500W 2000W 3000W 4000W 5000W 6000W 7000W
Peak power(20ms) 900VA 1500VA 3000VA 4500VA 6000VA 9000VA 4500VA 6000VA 9000VA 12KVA 15KVA 18KVA 21KVA
Input Stardard battery voltage 12VDC 24VDC 48VDC
AC input voltage range

73~138VAC(110VAC)/83~148VAC(120VAC)/ 145~275VAC(220VAC)/ 155~285VAC(230VAC)/165~295VAC(240VAC)

85VAC~138VAC (110VAC) / 95VAC~148VAC (120VAC) / 170VAC~275VAC (220VAC)/ 180VAC~285VAC (230VAC)/ 190VAC~295VAC (240VAC)
AC input frequency range 45Hz~55Hz(50Hz);55Hz~65Hz(60Hz)
Output Conversion efficiency ≥85%(Battery mode); >99%(AC mode)
AC Output voltage 110VAC±2% / 120VAC±2% / 220VAC±2% / 230VAC±2%/ 240VAC±2%(Battery mode);     110VAC±10% / 120VAC±10% / 220VAC±10% / 230VAC±10% / 240VAC±10%(AC mode)
AC Output frequency 50/60Hz±1%(Battery mode); Tracking Automatically(AC mode)
AC Output waveform Pure Sine Wave
THD ≤3%(Linear load)
DC Output voltage  4*DC 12V; 2*USB(5V)  4*DC 12V; 4*USB(5V)
AC charger AC charging current 0~30A(Depends on model)
AC charging method Three-stage(constant current, constant voltage, floating charge)
solar charger  (Optional) Charging mode PWM PWM/MPPT
Max PV input voltage(Voc)
(At the lowest temperature)
50V PWM: 50V; MPPT: 150V PWM: 100V; MPPT: 150V
PV input voltage range 15V~44V PWM:  30V~44V;  MPPT:  30V~120V PWM: 60V-88V;   MPPT: 60V-120V
Charge & discharge current 20A 40A 60A
Max PV input power 280W 560W 1680W 3360W
Inbuilt battery Capacity 1*50AH 1*100AH 2*200AH 4*200AH
Battery size(LxWxH)/pcs 229*138*210(228) 407*174*210(240) 522*240*218(244)
Other Transfer time ≤4ms
Protection with over-voltage, low-voltage, overload, short circuit, high tempreature protections
Display LCD & LED
Cooling way Cooling fan in intelligent control
Communication(Optional) RS485/APP(WIFI monitoring or GPRS monitoring)(Models below 1000W (including 1000W) are not supported)
Working mode
(selectable)
d1 AC priority mode
d2 ECO mode
d3 Solar priority mode
Work
environment
Operating temperature -10℃~40℃
Storage temperature -15℃~60℃
Elevation 2000m(More than derating)
Humidity 0%~95% ,No condensation
Physical Dimention L x W x H(mm) 358*192*390 488*232*450 560*350*928 610*535*960
Net weight(kg)(without battery) 8 10 16 37 39 43 53 55 59 61 63 64 66
Packing Dimention  L x W x H(mm) 400*252*500 550*295*625 638*427*1063 688*612*1093
Gross weight(kg)(without battery) 11 13 21 47 49 53 68 70 74 76 78 79 81
Quantity/CTN 1pcs per wooden case
Note: All specifications are subject to charge without prior notice

solar inverter with battery price




Application Of Solar Inverter With Battery



The function of solar inverter is to convert direct current into alternating current. Solar inverter with battery is to store energy. In addition, Xindun ESS series solar inverters also have the functions of stabilizing voltage and charging batteries. So, if you are in a place where there is no electricity, or the power environment is poor and the voltage is unstable, or want a device that can charge the battery, you can use ess solar inverter with battery. This is a solar inverter most suitable for off-grid solar energy system.

1kva 2kva solar inverter with battery application1kva 2kva solar inverter with battery application5kva solar inverter with battery application

1kva solar inverter with battery price




Solar Inverter With Battery Factory



Xindun factory is based in China and its products are already largely sold to more than 100 countries and regions. Our product range includes solar inverter, solar controller, solar generator, solar energy system, ups, battery, etc. Our products have passed CE, TUV and IEC test reports. Besides We have professional sales staff and we can offer you customized services and provide free solar energy solutions.



solar inverter with battery company xindun

solar inverter with batterysolar inverter with battery

1kva solar inverter with battery price

Inverter Factory

Xindun was a production-oriented enterprise at the beginning of its establishment in 2006. Engineering R&D personnel have grown from 2 at the beginning to 30 at present, production workers have grown from 10 at the beginning to 200 at present, and factory area has grown from 200 square meters at the beginning to 10,000 square meters at present. Now Xindun has become a high-tech enterprise integrating research and development, manufacturing, sales and export. There are 6 warehouses abroad. As the headstream factory, we can provide traders and retailers with the most beautiful inverter price and the most reliable inverter quality.



solar inverter with battery factory

china solar inverter with battery factory

5kva solar inverter with battery price




Solar Inverter FAQ



Q1: What is 1kva solar inverter with battery price/2kva solar inverter with battery price/5kva solar inverter with battery price?

With the market fluctuation, the solar inverter with battery price has been reduced recently. Please contact Xindun through the contact information at the bottom of the page.



Q2: Do I need a solar inverter with battery?

A machine contains inverter, batteries and solar controllers. You deserve such a convenient and practical machine.



Q3: Can I change the appearance or color of the solar inverter?

Yes of course. The customized services that Xindun inverter factory can provide to customers include but are not limited to: chassis appearance design, customer's trademark, change chassis color, special voltage and power.



Q4: Can you calculate the solar inverter with battery for me?

My pleasure. A special scheme calculation team will work out the scheme within 24 hours.



For any other questions about the solar inverter, please feel free to contact Xindun Power.
