HES PLUS All In One Inverter And Lithium Lifepo4 Battery 5KW-45KW

Input Voltage: 48VDC | Output Voltage: 220/230/240VAC±2% | Battery: LiFePO4 Lithium 51.2VDC 100Ah, Support Expansion | Solar Charging: MPPT | Max PV Open Circuit Voltage: 500VDC

1 : All in one design including mppt controller, solar inverter and lithium battery, reducing installation complexities and saving space.

2 : Lithium battery inverter support parallel operation, can output single-phase or three-phase electricity.

3 : Flexible energy storage capacity, supports three charging methods, solar charging, diesel and gasoline generator charging, and power grid charging.

4 : Lithium battery with BMS protection, lithium battery and inverter support communication.

5 : RS485, WIFI, GPRS App monitors inverter and lithium battery.

Produt Details Download

HES PLUS All In One Inverter and Lithium Battery



Want a one-stop energy storage solution? Xindun HES PLUS all in one lithium battery inverter controller, with the feature of fast installation, long life, save electricity bill and portable energy source. It is the most popular home energy storage product in the market from the 2022 to the present.

High frequency pure sine wave inverter, higher inverter conversion efficiency and more stable load output capability. MPPT controller has higher power generation efficiency. Moreover, the lithium lifepo4 battery is renowned for its longevity and eco-friendliness, reducing your carbon footprint and contributing to a sustainable future. This lithium battery inverter not only do 5kw capacity only, but also can maximum parallel connection to 9 units, that means, the power can be expanded to a maximum of 45kw, and both single-phase and three-phase loads can be used.

Elevate your energy efficiency and sustainability with the all in one battery and inverter. It's more than just an energy storage system, it's a revolution in power management. Experience uninterrupted, eco-friendly energy, and take control of your energy future. Welcome to a world where power is in your hands.



all in one lifepo4 inverterhes plus inverter lifepo4lifepo4 battery inverter mppt controllerall in one lifepo4 inverter details






All In One Inverter and Lithium Battery Technical Parameter



Model HES PLUS 50248
Power
Rated Power 5000W
Single/Parallel Support parallel operation, up to 9 units in parallel
(single-phase/three-phase)
Battery
Standard Battery Voltage 48VDC
Battery Type LiFePO4 battery
Battery Capacity 51.2VDC 100AH (Can parallel batteries, standard rack mount,19inch/3U)
Max Charge/Discharge Current 100A
Charge/Discharge Cut-Off Voltage 44.8VDC/58.4VDC
AC Input
AC Input Voltage 220VAC/230VAC/240VAC
AC Input Frequency 45Hz~55Hz(50Hz),55Hz~65Hz(60Hz)
AC Output
Output Wave Pure Sine Wave
 Conversion Efficiency(INV mode) 94%(peak value)
Output Voltage/Frequency (INV mode) 220VAC/230VAC/240VAC±2%/50Hz  ±1%,60Hz  ±1%
MPPT Solar Charge Controller

Max PV Input Voltage(Voc)
(At The Lowest Temperature)

500VDC
PV Array Maximum Power 6000W
MPPT Tracking Voltage Range 120V~450VDC
MAX PV Charging Current 80A
Other
Protection Battery undervoltage protection/Battery overvoltage protection/Overload power protection/Inverter output short circuit protection/Temperature protection
Protection Degree IP20
Display LCD+LED
Cooling Method Cooling fan in intelligent control
Communication USB/RS232 communication , mobile APP (WIFI monitoring or GPRS monitoring) Optional
Working Mode Mains priority/PV priority/Battery priority
Operating Temperature -15 ℃ ~40 ℃
Relative Humidity 0%-95% (No condensation)
Size
Product Size(L*W*Hmm) 525*180*900
Package Size(L*W*Hmm) 535*190*910






All In One Energy Storage System Wiring Diagram



All in one inverter battery prepare for the unexpected with built-in backup power capability. In the event of a grid outage, this energy system seamlessly switches to battery power, keeping your essential appliances running. Solar energy, diesel and gasoline generator power grid all can charge lithium lifepo4 battery. Say goodbye to disruptions during blackouts. The following is the wiring diagram of a single inverter battery.

lifepo4 inverter wiring diagram



Some clients may be worried, what if I need to expand the capacity of the inverter and battery in the future? The good news is that Xindun HES PLUS perfectly solves the expansion problem. The inverter supports 9 units in parallel, which can achieve 10kw, 15kw, 20kw... up to 45kw. Standard battery capacity is 51.2VDC 100AH, supports lithium lifepo4 battery expansion. Its robust design ensures consistent and dependable power generation. The following is the wiring diagram of the parallel inverter battery.



parallel lifepo4 inverter wiring diagram






All In One Inverter and Lithium Battery Factory



Xindun Power, Not just a factory, but a sustainable brand. Our manufacturing excellence is not just a commitment; it's a core part of our identity. We take pride in producing all in one inverter and battery solutions that are as reliable as they are innovative. When you partner with Xindun Power, you're choosing quality, customization, and sustainability, all backed by years of industry expertise.



lifepo4 inverter chinese factory



The 17-year-old factory only focuses on making battery and inverter. We continue to improve the appearance and performance of all in one inverter battery controller, and continue to make products in line with the market that changes every year. With 10,000 square meters of production space and 5,000 square meters of spot inventory, we have sufficient research and design capabilities to provide customized production for dealers and brands.



inverter lifepo4 battery factory



These certifications and endorsements are not just badges of honor for us; they are a testament to our unwavering commitment to our customers, the environment, and the advancement of the energy storage industry. When you choose Xindun Power, you're choosing batteries and inverters that have been rigorously tested, certified, and recognized for their quality and performance. We're proud of these achievements and look forward to continuing to set the industry standard for excellence.



inverter lifepo4 battery certificate



Global Reach, Local Production

While we serve customers worldwide, our local production capabilities ensure timely delivery and excellent support. Whether you're in Asia, Europe, or the Americas, you can count on Xindun Power for on-time delivery and responsive customer service.



xindun energy storage exhibition
