DP Hybrid Inverter With Solar Battery Charging 1000W-7000W

Input Voltage: 12/24/48VDC | Output Voltage: 110/120/220/230/240VAC±2% | Solar Charging: MPPT/PWM | Max PV Open Circuit Voltage: 50/100/150VDC

1 : Pure sine wave low frequency toroidal transformer increase efficiency.

2 : Hybrid inverter with inbuilt pwm or mppt solar charge controller.

3 : Gybrid inverter with solar charging and AC charging.

4 : Can communicate with lithium batteries, RS485/WIFI communication port.

5 : LCD display; One-button start with an external LCD display (optional)

hybrid inverter with solar battery charging system - Xindun China

DP Hybrid Inverter With Solar Battery Charging

DP Series Hybrid Inverter With Solar Battery Charging 1000W-7000W, Pure sine wave output, built-in toroidal transformer, can achieve 95% of high electrical efficiency, low vibration and noise, strong load impact resistance, ensuring smooth operation of the load. The solar battery charging configuration is more flexible, which can support AC charging, diesel or gasoline generator charging, and solar charging. Integrated LCD display and external display support viewing various data of inverter operation. The hybrid inverter can be equipped with a built-in MPPT or PWM solar controller to flexibly adjust the solar charging current.

high efficiency of hybrid inverter with solar battery charging system strong loads impact resistance of hybrid inverter with solar battery charging system hybrid inverter with external lcd display widely used of hybrid inverter with solar battery charging system

Hybrid Inverter Datasheet

Hybrid Inverter Specification
Model: DP		10212/24/48	15212/24/48	20212/24/48	30224/48	40224/48	50248	60248	70248
Rated Power		1000W	1500W	2000W	3000W	4000W	5000W	6000W	7000W
Peak Power（20ms)		3000VA	4500VA	6000VA	9000VA	12000VA	15000VA	18000VA	21000VA
Start Motor		1HP	1.5HP	2HP	3HP	3HP	4HP	4HP	5HP
Battery Voltage		12/24/48VDC			24/48VDC	24/48VDC	48VDC
Size(LWHmm)		555297184				615315209
Packing Size(LWHmm)		620345255				680365280
N.W.(kg)		12	13	15.5	18	23	24.5	26	27.5
G.W.(kg)（Carton Packing）		14	15	17.5	20	25.5	27	28.5	30
Installation Method		Wall-Mounted
Hybrid Inverter Parameter
Input	DC Input Voltage Range	10.5-15VDC（Single battery voltage）
	AC Input Voltage Range	85VAC~138VAC（110VAC）/ 95VAC~148VAC（120VAC / 170VAC~275VAC（220VAC / 180VAC~285VAC（230VAC） / 190VAC~295VAC（240VAC）
	AC Input Frequency Range	45Hz~55Hz(50Hz) / 55Hz~65Hz(60Hz)
	Max AC charging current	0~30A(Depending on the model）
	AC charging method	Three-stage (constant current, constant voltage, floating charge)
Output	Efficiency(Battery Mode)	≥85%
	Output Voltage(Battery Mode)	110VAC±2% / 120VAC±2% / 220VAC±2% / 230VAC±2% / 240VAC±2%
	Output Frequency(Battery Mode)	50/60Hz±1%
	Output Wave(Battery Mode)	Pure Sine Wave
	Efficiency(AC Mode)	>99%
	Output Voltage(AC Mode)	110VAC±10% / 120VAC±10% / 220VAC±10% / 230VAC±10% / 240VAC±10%
	Output Frequency(AC Mode)	Follow input
	Output waveform distortion (Battery Mode)	≤3%（Linear load）
	No load loss(Battery Mode)	≤0.8% rated power
	No load loss(AC Mode)	≤2% rated power（ charger does not work in AC mode）
	No load loss(Energy saving Mode)	≤10W
Battery Type	VRLA Battery	Charge Voltage :14V; Float Voltage:13.8V( 12V system; 24V system x2 ; 48V system x4)
	Customize battery	Charging and discharging parameters of different types of batteries can be customized according to user requirements (charging and discharging parameters of different types of batteries can be set through the operation panel)
Protection	Battery undervoltage alarm	Factory default: 11V(12V system; 24V system x2; 48V system x4)
	Battery undervoltage protection	Factory default: 10.5V(12V system; 24V system x2; 48V system x4)
	Battery overvoltage alarm	Factory default: 15V(12V system; 24V system x2; 48V system x4)
	Battery overvoltage protection	Factory default: 17V(12V system; 24V system x2; 48V system x4)
	Battery overvoltage recovery voltage	Factory default: 14.5V(12V system; 24V system x2; 48V system x4)
	Overload power protection	Automatic protection (battery mode), circuit breaker or insurance (AC mode)
	Inverter output short circuit protection	Automatic protection (battery mode), circuit breaker or insurance (AC mode)
	Temperature protection	>90°C（Shut down output）
Alarm	A	Normal working condition, buzzer has no alarm sound
	B	Buzzer sounds 4 times per second when battery failure, voltage abnormality, overload protection
	C	When the machine is turned on for the first time, the buzzer will prompt 5 when the machine is normal
Inside Solar controller (Optional)	Charging Mode	PWM or MPPT
	Charging current	10A~60A（PWM or MPPT）				10A~60A(PWM ) / 10A~100A(MPPT)
	PV Input Voltage Range	PWM: 15V-44V(12V system); 30V-44V(24V system); 60V-88V(48V system) MPPT: 15V-120V(12V system); 30V-120V(24V system); 60V-120V(48V system)
	Max PV Input Voltage(Voc) (At the lowest temperature)	PWM: 50V(12V/24V system); 100V(48V system) / MPPT: 150V(12V/24V/48V system)
	PV Array Maximum Power	12V system: 140W(10A)/280W(20A)/420W(30A)/560W(40A)/700W(50A)/840W(60A)/1120W(80A)/1400W(100A); 24V system: 280W(10A)/560W(20A)/840W(30A)/1120W(40A)/1400W(50A)/1680W(60A)/2240W(80A)/2800W(100A); 48V system: 560W(10A)/1120W(20A)/1680W(30A)/2240W(40A)/2800W(50A)/3360W(60A)/4480W(80A)/5600W(100A)
	Standby loss	≤3W
	Maximum conversion efficiency	>95%
Working Mode		Battery First/AC First/Saving Energy Mode
Transfer Time		≤4ms
Display		LCD（External LCD Display(Optional)）
Thermal method		Cooling fan in intelligent control
Communication(Optional)		RS485/APP（WIFI monitoring or GPRS monitoring）
Environment	Operating temperature	-10℃~40℃
	Storage temperature	-15℃~60℃
	Noise	≤55dB
	Elevation	2000m（More than derating）
	Humidity	0%~95% ,No condensation
Note: All specifications are subject to charge without prior notice

How to Use Hybrid Inverter Correctly

According to this wiring diagram, you can clearly see the correct use of this hybrid inverter. The hybrid inverter can be connected to the power supply through solar panels, mains power, or generators, which can be stored in a battery or directly supply power to DC or AC loads.

how to use hybrid inverter with solar battery charging system

Hybrid Inverter Application

This hybrid inverter has a wide range of applications, including home backup power supply, commercial use, agricultural irrigation, outdoor RV mobile power, transportation vehicles, etc., solving the power consumption problem.

application of hybrid inverter with solar battery charging system

Hybrid Inverter Strong Packaging

Strong packaging quality is as important as good product quality. Reliable packaging can help to sell products. We ensure that hybrid inverters can be delivered to customers quickly, economically, and safely.

package of hybrid inverter with solar battery charging

Hybrid Inverter Company in China

For more than 16 years, China Xindun Power has developed the solar energy sector with its powerful inverter technology. We have partnered with agents in more than a hundred various countries. We have included the most recent inverter technology from both domestic and international sources, and we are constantly developing and upgrading our R&D and production technology. As a result, our staff members is always getting better. Xindun Power is able to guarantee the effectiveness and quality of the production of hybrid inverters thanks to its more than 200 employees and senior technical engineers with more than 17 years of experience in the industry.

hybrid inverter system company in china

Hybrid Inverter Factory

Xindun has a production space of approximately 10000 square meters, 8 production lines, and 5 medium to large production and testing equipment. In addition to wholesale a variety of models of inverters from stock, our hybrid inverters can also undergo OEM/ODM to meet the unique needs of customers. Voltage, power, pattern design, logo, and other unique parameter settings are included in the customizable range. Engineers provide customized solution services one-on-one. Quickly contact Xindun to obtain a customized process for the hybrid inverter with solar battery charging.
